6mm+12A+6mm Clear tempered insulated glass,24mm clear tempered IGU manufacturer China
Product Introduction:
Other name: Hollow glass, heat proof glass, sound insulation glass, double glazing/double glazed glass, insulating glass, IGU
Shape: Flat insulated glass, curved insulated glass
Composititon: Glass+aluminum insulation spacer+glass
Single Glass Thinckness: 5mm to 10mm
Insulated glass glue: Butyl glue and sulfur glue
Spacer thinckness: 6A 9A 12A 15A 20A 27A 32A
Package: Strong exportation wood crates
Delivery: 10-15 working days after deposit payment received
Product details
BTG 6mm+12A+6mm Clear tempered insulated glass,24mm clear tempered IGU manufacturer China-SOUND PROOF GLASS & HEAT INSULATION GLASS & SOLAR ENERGY SAVING GLASS BUILDING MATERIAL
6mm+12A+6mm Clear tempered insulated glass,24mm clear tempered IGU manufacturer China(IGUs) also called insulated glass unit, insulated glazing units, thermal insulation units, double pane glass, dual pane glass, double pane insulated glass, thermal insulation glass, thermal seal insulating glass, double insulated glass. Insulated glass is composed of two or more layers of flat/curved glass, surrounded by high-strength high-density composite adhesive, the two or more pieces of 8mm tempered glass and seal, the glass of the bonding and sealing. The middle filled with dry gas, the spacer filled with desiccant to ensure that the glass between the air dryness. The fuction of air/gas spacer is reduce water vapor penetration. The insulated glass unit is sealed by a secondary edge seal and that make structural robustness to the insulated glass. The aluminum spacer contains a desiccant and can absorb humidity from or within the air space.
Characteristics:
Insulated glass combine with a solar control glass in a double glazed unit. The best advantages for insulated glass is to reduce thermal losses and the best way to improve the energy efficiency of a window or facade is insulated glass units.
1. Energy-saving effect. To reduce the indoor heating, play a great efficiency. Therefore, the greater the window opened, the more obvious energy-saving effect.
2. Improve the indoor environment. High-proformance insulating glass can intercept the considerable energy from the sun into the room, thus preventing discomfort caused by radiant heat and reducing dizziness caused by sunset sunlight.
3. Rich colors and artistic. High-performance insulating glass has a variety of colors, can be selected according to the color, in order to achieve better artistic results.
4. Constant temperature and humidity of the spacial buildings. High-performance insulating glass use. For office buildings, exhibition room, libraries and other public facilities and computer room, precision instrument workshops, chemical plants and other requirements of constant temperature and humidity of the special buildings.
5. Sun protection and anti-evening light dazzling place. Insulated glass can be used for sun protection and anti-evening light dazzling place.
Applications:
Insulating glass is mainly used for outer glass decoration. Its optical properties, thermal conductivity, sound insulation coefficient should be consistent with international standards. Reasonable structure and design to meet the standards of the hollow glass, in order to play its insulation, proof noise, security, proof fire effect.
Insulating glass is mainly used for buildings that require heating, air conditioning, noise or condensation protection, and the need for direct sunlight and special light. Widely used in residential, hotels, office buildings, schools, hospitals, shops and other indoor air conditioning. Can also be used for trains, cars, ships, doors and windows, freezer, ect.
1. Butyl glue insulated glass are used outside. Sulfur glue insulated glass are used inside.
2. Outside usage: Curtain wall glass, facade glass etc.
3. Inside usage: Window glass, door glass, railing glass etc.
Certification:
6mm+12A+6mm Clear tempered insulated glass,24mm clear tempered IGU manufacturer China Conforms to the standards of Europe, North American and China: ISO, CCC, CE, BS6206, EN12510, SGCC,CSI
Sr. | Item | Glass Type | Material option | Thickness(mm) | PVB/EVA/SGP/Alu. thickness(mm) | Size | Remark | |
Min.(mm) | Max(mm) | |||||||
1 | Building Glass | Tempered Glass(Monolithic) | Clear glass | 3-25 | / | 200*300 | 3300*13000 | Contact us for more information |
2 | Low iron /Ultra clear glass | 3-25 | / | 200*300 | 3300*13000 | |||
3 | Tinted glass | 3-19 | / | 200*300 | 3300*13000 | |||
4 | Coated/Reflective glass | 5,6,8,10 | / | 200*300 | 3300*13000 | |||
5 | Low E glass | 5,6,8,10 | / | 200*300 | 3300*13000 | |||
6 | Curved Tempered Glass(Monolithic) | Clear glass | 3-25 | / | Radius>1000mm ,Radius<1000mm | |||
7 | Low iron /Ultra clear glass | 3-25 | / | |||||
8 | Tinted glass | 3-25 | / | |||||
9 | Coated/Reflective glass | 5,6,8,10 | / | |||||
10 | Low E glass | 5,6,8,10 | / | |||||
11 | Laminated Glass | Clear glass | 3-25 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | ||
12 | Low iron /Ultra clear glass | 3-25 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
13 | Tinted glass | 5,6,8,10,12 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
14 | Coated/Reflective glass | 5,6,8,10,12 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
15 | Insulated Glass | Clear glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | ||
16 | Low iron /Ultra clear glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
17 | Tinted glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
18 | Coated/Reflective glass | 5,6,8,10 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
19 | Low E glass | 5,6,8,10 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
20 | Bullet Proof Glass | Bullet Proof Glass | 0.76 up | 200*300 | 2450*4500 | |||
21 | Fire Proof Glass | Single piece | 5-15 | / | 200*300 | 3000*4000 | 0.5h,1h,1.5h,2h,3h | |
22 | Compound glass | 5-45 | Customized | 200*300 | 3300*6500 | |||
23 | Switchable Glass | Switchable glass | 6-24 | 0.38,0.76,1.14 up | 200*300 | 1800*6000 | Contact us for more information | |
24 | Louver Product | 5-19 | 9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
25 | Sound Proof Glass | Sound proof glass | 5-19 | Customized | 200*300 | 3300*6500 |
