10.38mm clear laminated glass
Product Introduction:
Glass name: 10.38mm clear laminated glass
Other name: 10.38mm toughened laminated glass / 10.38mm safety lamianted glass / 10.38mm VSG ESG glass
Composition: 5mm clear tempered glass + 0.38PVB + 5mm clear tempered glass
Thickness: 9.52mm laminated glass, 11.52mm laminated glass, 17.52mm laminated glass, 21.52mm laminated glass, 25.52mmlaminated glass, 31.52mm laminated glass, 39.52mm laminated glass etc.
PVB color: Bronze, blue, dark gery, light grey, green, F green, ocean blue etc.
Shape: Flat or curved
Product details
BTG 10.38mm clear laminated glass-building glass manufacturers
10.38mm clear laminated glass also known as toughened safety glass 10.38mm,is a kind of laminated glass. Laminated glass is made of two or more pieces of clear tempered glass which one layer or multi-layers of EVA/PVB/SGP with strong cohesion sandwiched under high temperature and pressure between them. The appearance and installation method of laminated glass sandwiched with the transparent film is the same with normal glass, but much more durable.
Specification of laminated glass:
Glass thickness: 10.38mm clear tempered laminated glass
Other glass thickness: 9.38mm laminated glass, 11.52mm laminated glass, 17.52mm laminated glass, 21.52mm laminated glass etc.
Min size: 300*300mm
Max size: 2440*3300mm
Color: Clear laminated glass, ultra-clear laminated glass, Bronze laminated glass, blue laminated glass, dark grey laminated glass, light grey laminated glass, green laminated glass, F green laminated glass, ocean blue laminated glass, etc.
Characteristics of laminated glass:
1. Safety. In the external impact, due to the elastic layer of the role of the impact of absorption Can prevent the impact of penetration, even the glass is broken, but only produce spider-like crushing cracks Its debris firmly adhered to the middle layer will not fall off and scattered and can continue to use until more change.
2. Anti-theft. 10.38mm clear tempered laminated glass is very tough, even if the thieves broken glass. because the middle layer with the glass firmly together to keep integrity.
3. Sound insulation. 10.38mm clear tempered laminated glass because of the damping function of the acoustic wave, 13.52mm clear tempered laminated glass can have Effectively suppressed the spread of noise, especially in the airport, station, downtown, and roads on both sides of the building After the installation of laminated glass, the sound insulation effect is very obvious.
4. Anti-ultraviolet performance. 10.38mm clear tempered laminated glass can absorb more than 99% of the UV, thus protecting the Indoor furniture, plastic products, textiles, carpets, artwork, ancient artifacts, or goods from UV Radiation of the line and the occurrence of fading and aging.
5. Energy-saving. 10.38mm clear tempered laminated glass made of building laminated glass can effectively reduce the sunlight through. The thickness of the use of dark low light transmittance PVB film made of laminated glass to block the heat more powerful. At present, domestic production of laminated glass with a variety of colors.
Applications:
10.38mm clear tempered laminated glass can absorb the impact energy, does not produce broken pieces.
This safety glass is widely used :
1. At the same time in the construction of curtain walls, recruiting, window, bank counters, prison visits, steel stove screens.
2. A variety of bullet-proof glass and other construction areas are also widely used.
Certification:
10.38mm clear tempered laminated glass conforms to the standards of Europe, North American, and China: ISO, CCC, CE, BS6206, EN12510, SGCC, CSI
Product details:
Sr. | Item | Glass Type | Material option | Thickness(mm) | PVB/EVA/SGP/Alu. thickness(mm) | Size | Remark | |
Min. (mm) | Max(mm) | |||||||
1 | Building Glass | Tempered Glass(Monolithic) | Clear glass | 3-25 | / | 200*300 | 3300*13000 | Contact us for more information |
2 | Low iron /Ultra-clear glass | 3-25 | / | 200*300 | 3300*13000 | |||
3 | Tinted glass | 3-19 | / | 200*300 | 3300*13000 | |||
4 | Coated/Reflective glass | 5,6,8,10 | / | 200*300 | 3300*13000 | |||
5 | Low E glass | 5,6,8,10 | / | 200*300 | 3300*13000 | |||
6 | Curved Tempered Glass(Monolithic) | Clear glass | 3-25 | / | Radius>1000mm ,Radius<1000mm | |||
7 | Low iron /Ultra-clear glass | 3-25 | / | |||||
8 | Tinted glass | 3-25 | / | |||||
9 | Coated/Reflective glass | 5,6,8,10 | / | |||||
10 | Low E glass | 5,6,8,10 | / | |||||
11 | Laminated Glass | Clear glass | 3-25 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | ||
12 | Low iron /Ultra clear glass | 3-25 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
13 | Tinted glass | 5,6,8,10,12 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
14 | Coated/Reflective glass | 5,6,8,10,12 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
15 | Insulated Glass | Clear glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | ||
16 | Low iron /Ultra clear glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
17 | Tinted glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
18 | Coated/Reflective glass | 5,6,8,10 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
19 | Low E glass | 5,6,8,10 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
20 | Bullet Proof Glass | Bullet Proof Glass | 0.76 up | 200*300 | 2450*4500 | |||
21 | Fire Proof Glass | Single piece | 5-15 | / | 200*300 | 3000*4000 | 0.5h,1h,1.5h,2h,3h | |
22 | Compound glass | 5-45 | Customized | 200*300 | 3300*6500 | |||
23 | Switchable Glass | Switchable glass | 6-24 | 0.38,0.76,1.14 up | 200*300 | 1800*6000 | Contact us for more information | |
24 | Louver Product | 5-19 | 9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
25 | Sound Proof Glass | Soundproof glass | 5-19 | Customized | 200*300 | 3300*6500 |
