25.52mm tempered laminated glass,25.52mm toughened laminated glass
Product Introduction:
Glass name: 25.52mm tempered laminated glass,25.52mm toughened laminated glass
Other name: 25.52mm tempered laminated glass / 25.52mm toughened laminated glass / 25.52mm VSG
Composition: 12mm clear tempered glass + 1.52PVB + 12mm clear tempered glass
Other glass thickness: 9.52mm laminated glass, 11.52mm laminated glass, 17.52mm laminated glass, 21.52mm laminated glass, 25.52mmlaminated glass, 31.52mm laminated glass, 39.52mm laminated glass etc.
PVB Color: Bronze, blue, dark gery, light grey, green, F green, ocean blue etc.
Shape: Flat or curved
Interlayer material: PVB or SGP
Product details
BTG 25.52mm tempered laminated glass,25.52mm toughened laminated glass - BUILDING COMMERCIAL GLASS MANUFACTURERS FACTORY IN CHINA
25.52mm tempered laminated glass,25.52mm toughened laminated glass also know as toughened safety glass 25.52mm,is a kind of laminated glass. Laminated glass is made of two or more pieces of clear tempered glass which one layer or multi-layers of EVA/PVB/SGP with strong cohesion sandwiched under high temperature and pressure between them. The appearance and installation method of laminated glass sandwiched with transparent film are the same with normal glass, but much more durable.
Specification of laminated glass:
Glass thickness: 25.52mm tempered laminated glass,25.52mm toughened laminated glass
Other glass thickness: 9.52mm laminated glass, 11.52mm laminated glass, 17.52mm laminated glass, 21.52mm laminated glass, 25.52mmlaminated glass, 31.52mm laminated glass, 39.52mm laminated glass etc.
Min size: 300*300mm
Max size: 2440*3300mm
Color: Clear laminated glass, ultra clear lamianted glass, Bronze lamianted glass, blue lamianted glass, dark gery lamianted glass, light grey lamianted glass, green lamianted glass, F green lamianted glass, ocean blue lamianted glass ect.
PVB thickness: 0.38mm 0.76mm 1.14mm 1.52mm 1.9mm ect.
Characteristics of laminated glass:
1. Safety. In the external impact, due to the elastic layer of the role of the impact of absorption Can prevent the impact of penetration, even the glass is broken, but only produce spider-like crushing cracks Its debris firmly adhered to the middle layer will not fall off and scattered and can continue to use until more change.
2. Anti-theft. 25.52mm tempered laminated glass,25.52mm toughened laminated glass is very tough, even if the thieves broken glass. because the middle Layer with the glass firmly together to keep the integrity.
3. Sound insulation. 25.52mm tempered laminated glass,25.52mm toughened laminated glass because of the damping function of the acoustic wave, 13.52mm clear tempered laminated glass can have Effectively suppress the spread of noise, especially in the airport, station, downtown and roads on both sides of the building After the installation of laminated glass, the sound insulation effect is very obvious.
4. Anti-ultraviolet performance. 25.52mm tempered laminated glass,25.52mm toughened laminated glass can absorb more than 99% of the UV, thus protecting the Indoor furniture, plastic products, textiles, carpets, artwork, ancient artifacts or goods from UV Radiation of the line and the occurrence of fading and aging.
5. Energy-saving. 25.52mm tempered laminated glass,25.52mm toughened laminated glass made of building laminated glass can effectively reduce the sunlight through. with The thickness of the use of dark low light transmittance PVB film made of laminated glass to block the heat more powerful. At present, domestic production of laminated glass with a variety of colors.
Applications of laminated glass:
25.52mm tempered laminated glass,25.52mm toughened laminated glass can absorb the impact energy, does not produce broken pieces.
This safety glass is widely used :
1. Automobiles, commercial buildings, bank counters, all kinds of bullet-proof glass.
2. At the same time in the construction of curtain walls, recruiting, window, bank counters, prison visits, steel stove screen.
Certification of laminated glass:
25.52mm tempered laminated glass,25.52mm toughened laminated glass conforms to the standards of Europe, North American and China: ISO, CCC, CE, BS6206, EN12510, SGCC,CSI
Product details:
Sr. | Item | Glass Type | Material option | Thickness(mm) | PVB/EVA/SGP/Alu. thickness(mm) | Size | Remark | |
Min.(mm) | Max(mm) | |||||||
1 | Building Glass | Tempered Glass(Monolithic) | Clear glass | 3-25 | / | 200*300 | 3300*13000 | Contact us for more information |
2 | Low iron /Ultra clear glass | 3-25 | / | 200*300 | 3300*13000 | |||
3 | Tinted glass | 3-19 | / | 200*300 | 3300*13000 | |||
4 | Coated/Reflective glass | 5,6,8,10 | / | 200*300 | 3300*13000 | |||
5 | Low E glass | 5,6,8,10 | / | 200*300 | 3300*13000 | |||
6 | Curved Tempered Glass(Monolithic) | Clear glass | 3-25 | / | Radius>1000mm ,Radius<1000mm | |||
7 | Low iron /Ultra clear glass | 3-25 | / | |||||
8 | Tinted glass | 3-25 | / | |||||
9 | Coated/Reflective glass | 5,6,8,10 | / | |||||
10 | Low E glass | 5,6,8,10 | / | |||||
11 | Laminated Glass | Clear glass | 3-25 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | ||
12 | Low iron /Ultra clear glass | 3-25 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
13 | Tinted glass | 5,6,8,10,12 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
14 | Coated/Reflective glass | 5,6,8,10,12 up | 0.38,0.76,1.14 up | 200*300 | 3300*6500 | |||
15 | Insulated Glass | Clear glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | ||
16 | Low iron /Ultra clear glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
17 | Tinted glass | 3-25 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
18 | Coated/Reflective glass | 5,6,8,10 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
19 | Low E glass | 5,6,8,10 | 6,9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
20 | Bullet Proof Glass | Bullet Proof Glass | 0.76 up | 200*300 | 2450*4500 | |||
21 | Fire Proof Glass | Single piece | 5-15 | / | 200*300 | 3000*4000 | 0.5h,1h,1.5h,2h,3h | |
22 | Compound glass | 5-45 | Customized | 200*300 | 3300*6500 | |||
23 | Switchable Glass | Switchable glass | 6-24 | 0.38,0.76,1.14 up | 200*300 | 1800*6000 | Contact us for more information | |
24 | Louver Product | 5-19 | 9,12,16,,18,20 up | 200*300 | 3300*6500 | |||
25 | Sound Proof Glass | Sound proof glass | 5-19 | Customized | 200*300 | 3300*6500 |
